AD4Q

FOUR-CHANNEL DIGITAL WIRELESS RECEIVER

MAIN FEATURES

Wide tuning range up to 184 MHz
True digital diversity reception per channel for drop-out resistance
Networked control with Wireless Workbench® software and ShurePlus™ Channels iOS app
Quadversity mode for extended antenna coverage and improved RF signal-to-noise
Front panel headphone jack enables Dante™ Cue and Dante™ Browse monitoring
Configurable Ethernet switch for redundant Dante or AES67 digital output
Switchable XLR and AES3 outputs
Channel Quality meter displays RF signal-to-noise
DC module version available to support redundant power

AD4D

TWO-CHANNEL DIGITAL WIRELESS RECEIVER

MAIN FEATURES

Works with Axient™ Digital Wireless Systems
Features networked control and signal routing options, plus mobile monitoring and control capabilities
Available with or without accessories
Wide tuning range up to 184 MHz
True digital diversity reception per channel for drop-out resistance
Networked control with Wireless Workbench® software and ShurePlus™ Channels iOS app
Front panel headphone jack enables Dante™ Cue and Dante™ Browse monitoring
Configurable Ethernet switch for redundant Dante or AES67 digital output
AES3 output

Receiver

AD1

BODYPACK TRANSMITTER

MAIN FEATURES

Two transmission modes: Standard for optimal coverage and new High Density for maximum system channel count and robust coverage
Encryption-enabled, secure transmission
Two connector options: TA4 and LEMO3
Detachable ¼-wave antenna
AA or SB900A lithium-ion rechargeable batteries for convenient power options
External contacts for docked charging

AD2

HANDHELD TRANSMITTER

AD2/SM58
AD2/B58A
AD2/B87A
AD2/B87C
AD2/KSM8
AD2/KSM9
AD2/KSM9HS

AD2/SM58 - AD2/B58A

AD2/B87 - AD2/B87C

AD2/KSM8

AD2/KSM9 - AD2/KSM9HS

Mic Capsule

MAIN FEATURES

Works with Axient™ Digital Wireless Systems
Offers more than 11 hours of continuous battery life with Shure lithium-ion rechargeable batteries or 8 hours with AA batteries at 10 mW
Two transmission modes: Standard for optimal coverage and new High Density for maximum system channel count and robust coverage
Rugged metal construction in black finish
Backlit LCD with easy-to-navigate menu and controls
Low-profile, lockable power switch
Encryption-enabled, secure transmission
AA or SB900A lithium-ion rechargeable batteries for convenient power options
External contacts for docked charging

Transmitter

ULX-D
DIGITAL WIRELESS SYSTEM

MAIN FEATURES

Available Transmitter Form factors: Boundary, Handheld, Bodypack, Desktop base
Operating range (up to): 100 m (Under typical conditions)
24 bit / 48 kHz digital audio
Over 120 dB dynamic range, 130 dB (typical) using Dante™ digital networked audio
Built-in limiter circuitry prevents digital audio clipping
Compatible with Wireless Workbench® 6 software, for advanced frequency coordination, monitoring, and control
AES-256 bit encryption offers unbreachable privacy, and eliminates stray RF interference by only allowing the encrypted signal through to the receiver
Selectable 1, 10, and 20 mW transmitter RF output power

ULXD4Q

DIGITAL QUAD WIRELESS RECEIVER

ULXD4D

DIGITAL DUAL WIRELESS RECEIVER

ULXD4

DIGITAL WIRELESS RECEIVER

Receiver

DIGITAL BODYPACK TRANSMITTER

ULXD1

WIRELESS BOUNDARY MICROPHONE TRANSMITTER

ULXD6

WIRELESS GOOSENECK BASE TRANSMITTER

ULXD8

ULXD2 DIGITAL HANDHELD TRANSMITTER WITH SM58 CAPSULE

ULXD2/SM58

ULXD2 DIGITAL HANDHELD TRANSMITTER WITH BETA 58A CAPSULE

ULXD2/B58

Transmitter

ULXD2 DIGITAL HANDHELD TRANSMITTER WITH SM86 CAPSULE

ULXD2/SM86

ULXD2 DIGITAL HANDHELD TRANSMITTER WITH SM87 CAPSULE

ULXD2/SM87

ULXD2 DIGITAL HANDHELD TRANSMITTER WITH BETA 87A CAPSULE

ULXD2/B87A

ULXD2 DIGITAL HANDHELD TRANSMITTER WITH BETA 87C CAPSULE

ULXD2/B87C

ULXD2 DIGITAL HANDHELD TRANSMITTER WITH KSM8 CAPSULE

ULXD2/K8

ULXD2 DIGITAL HANDHELD TRANSMITTER WITH KSM9 CAPSULE

ULXD2/KSM9

ULXD2 DIGITAL HANDHELD TRANSMITTER WITH KSM9HS CAPSULE

ULXD2/KSM9HS

Compatible with ULX-D & QLX-D

ULX-D6

Wireless Boundary Microphone Transmitter

ULX-D8

Wireless Gooseneck Base Transmitter

WIRELESS BOUNDARY MICROPHONE TRANSMITTER

ULXD6

WIRELESS GOOSENECK BASE TRANSMITTER

ULXD8

MAIN FEATURES

Available Transmitter Form factors: Boundary, Handheld, Desktop base, Bodypack
Transparent 24-bit digital audio captures every performance detail
Extended 20 Hz to 20 kHz frequency range (microphone dependent)
Up to 64 MHz tuning bandwidth (region dependent)
Easy pairing of transmitters and receivers over IR scan and sync
Automatic channel scan quickly and easily finds a clean frequency
Ethernet networking for multiple receiver systems
Networked channel scan configures open frequencies for connected receivers
AES-256 encryption for secure wireless transmission
Compatible with Shure Wireless Workbench® 6 control software

System Pack Configure

MXWANI8
MXWNCS8
MXW8
MXW8-WH
MXW6
MXW6-WH
MXW1
MXW2-SM58
MXWAPT8

MXW Feature

Wireless transmission uses DECT technology for more than 80 audio channels per system
Encrypted wireless: AES 256-bit encryption for secure transmission
Automated frequency coordination: Automatically scans available spectrum, coordinates clean frequency assignments, and moves channels away from unexpected interference
Bi-directional wireless: Provides return channel audio to wireless transmitters and enables real time remote control of all wireless microphone settings
Dante™ digital networked audio: Transports low latency digital audio received from wireless microphones over Cat5e cable to any other Dante-equipped device
Scalable configurations: Available in 4 or 8 channel models to fit varying channel count requirements, and multiple units can be combined support configurations of up to 32 compatible channels
